C21000 Copper Plate

Product description:

Copper plate has good mechanical properties, good plasticity in hot state, fair plasticity in cold state, good machinability, easy fiber welding and welding, corrosion resistance, and cheap price. It is a common copper variety widely used.

Consulting products

E-mail:cathy@jsrzss.com

Whatsapp:8618021160996

Product Details

Copper plate / Copper sheet
Production Standard	ASTM, AISI,JIS, DIN, EN,GB, GOST
Size	Width	20mm-2500mm or as the customer’s request
	Thickness	0.1mm-250mm or as the customer’s request
	Length	50mm-12000mm or as the customer’s request
Hardness	O, 1/16 Hard, 1/8 Hard, 1/4 Hard, 3/8 Hard, 1/2Hard, 3/4 Hard, H, EH
Surface	mill,polished,bright,oiled,hair line,brush,mirror,sand blast,or as required
OEM Service	Perforated, Cutting special size, Doing flatness, Surface treatment, etc
Delivery Time	Within 3 days for our stock size, 7-15 days for our production
Package	Export standard package: bundled wooden box, suit for all kinds of transport,or be required
Sample	Free and available
Quality	Mill Test Certificate, ISO9001, CE,SGS, TVE
Processing Service	Bending, Welding, Decoiling, Cutting, Punching
Advantage	Copper is a very ductile and malleable metal. It is high electrical conductivity and high thermal conductivity. Thus, copperparts have a significant advantage for the production of electronic and electrical components.

Product Material

Chemical Composition:

Grade			Chemical Composition(%)
	GB	JIS	Cu+Ag	P	Bi	Sb	As	Fe	Ni	Pb	Sn	S	Zn	O
Refined Copper	T1	C1020	99.95	0.001	0.001	0.002	0.002	0.005	0.002	0.003	0.002	0.005	0.005	0.02
	T2	C1100	99.9	-	0.001	0.002	0.002	0.005	-	0.005	-	0.005	-	-
	T3	C1221	99.7	-	0.002	-	-	-	-	0.01	-	—	-	-
Oxygen Free Copper	TU0	C1011	99.99	0.0003	0.0001	0.0004	0.0005	0.001	0.001	0.0005	0.0002	0.0015	0.0001	0.0005
	TU1	C1020	99.97	0.002	0.001	0.002	0.002	0.004	0.002	0.003	0.002	0.004	0.003	0.002
	TU2	C1020	99.95	0.002	0.001	0.002	0.002	0.004	0.002	0.004	0.002	0.004	0.003	0.003

Mechanical Properties:

Grade (JIS)	Temper	Vickers Hardness (HV)	Tensile Strength (Mpa)	Elongation (%)
C1100C1201C1220etc.	M (Soft)	≤70	≥195	≥30
	Y4 (1/4H)	60-95	215-295	≥25
	Y2 (1/2H)	80-110	245-345	≥8
	Y (Full Hard)	90-120	295-395	≥3
	T (Extra Hard)	≥110	≥350	-
